TitanPro Cutting
TitanPro Cutting
| Model NO. | 1325M | Condition | New |
|---|---|---|---|
| Certification | CE | CNC or Not | CNC |
| Voltage | AC220V/50Hz | Machine Type | CNC Router |
| XYZ Axis Travel | 1300*2500*200mm | Feeding Height | 200mm |
| Spindle Power | 4.5kw Air Cooling Spindle | Drive Type | Servo Motor |
| Max Travel Speed | 40000mm/Min | Working Precision | 0.05mm |
| Command Code | G Code | Rail Type | Linear Rails |
| Production Capacity | 500 Sets/Month | Origin | Mainland China |
1. Advertisement industry: Acrylic, PVC, ABS plate, aluminum plate
2. General wood working industry: Furniture decoration, instrument manufacturing, wooden craft, solid wood furniture, MDF
3. Decoration industry: Art model, mural, screen, gift packing
4. Mould industry: Casting, spaceflight, craft, rail traffic
| XYZ axis travel | 1300x2500x200mm |
|---|---|
| Feeding height | 200mm |
| Table size | 1300*2500mm |
| Spindle power | 4.5KW air cooling spindle (0-18000RPM) |
| Control system | PC controller system/DSP/NK105G3 |
| Drive type | Servo motor |
| Rail type | Linear rails |
| Transmit | XY gear rack and Z ballscrew |
| Table type | Vacuum absorption with T slot clamping |
| Working precision | 0.05mm |
| Compatible Software | Type3/Artcam/UG/Pro-E/Mastercam/Ucancam etc |
| Net / Gross weight | 1300kg / 1700kg |
The Strong version 1325/1530/2030 stands as a benchmark for big size CNC equipment, integrating industrial-grade features that prioritize power, stability, and precision. It is equipped with a 4.5KW high-power air-cooled spindle, delivering rotational speeds up to 18000 RPM for efficient cutting and engraving of tough materials like steel, stone, and thick wood.
Constructed with high-grade, corrosion-resistant steel, each model undergoes strict quality testing, including 72 hours of continuous load trials, reflecting our commitment to delivering reliable, low-maintenance equipment.
